BIM

BIM – fast, accurate and efficient

Did you know the edilon)(sedra Application Engineering department supports you applying BIM in your railway infrastructure project? Our BIM library offers a selection of edilon)(sedra track systems, ready to be integrated in the track alignments of your project.

We are currently working on a new BIM library. In case you need any support, please get in touch with our BIM experts in Madrid by phone T +34 912 65 51 73 or mail@edilonsedra.com

Please accept marketing cookies to view this content.

Valencia line 10

FGV is the first railway administration in Spain which is managing projects applying the BIM philosophy. BIM plays an important role within project ‘Valencia line 10’: a new metro line to be built between the stations of Alicante and Nazaret in Valencia. edilon)(sedra provided BIM Objects of the Corkelast® ERS track system to the involved project partners. The project ‘Valencia line 10’ is divided in two sections for both of which we supply our Corkelast® ERS (Embedded Rail System):
Alicante – Amado Granell: a tunnel of 2,5 km of double track
Amado Granell – Nazaret: different track sections, like grass track and bridge track

View a 360 experience

En Chardon depot

For depot project En Chardon in Geneva Switzerland, we provided our customer with a specific working methodology for Corkelast® ERS in switches and supported the planning of the construction. To smoothen planning and construction work the University of Geneva developed a BIM model to avoid building constraints during realization. edilon)(sedra provided BIM Objects to support the track realization.

More information?

As international supplier of ballastless track systems, we offer more than 50 years of track experience and provide you with technical support in different stages of your railway project.

Our departments across the world employ skilled and highly motivated people with years of experience in the rail industry.

Do you have questions about your project, our track system solutions or added value services? Would you like to work within our company and improve your skills in track technology, sales, finance or otherwise? Can we support you with anything else?
